Series: W83 Series
Rated Current: 20AX 250V~
Model No.: W83/20L1
Color: White
Warranty: 10 years
Standard: British
Certificates: CB, CE, SASO
Light Switch & Socket 850℃ Glow Wire Test Video:
W83 series featuring a elegant style, can be attractive in any interior, whether office or commercial or hotels, and extends to everything from USB Socket , dimmers switches to euro plates & modules and data connections.
Product Introduction of the 20AX 250V Double Pole Switch with Neon - White 1 Gang
1. The7mm cover panel is made of good quality PC material combining a matt switch button with gorgeous neon, which shows understated elegant.
2. Neonindicator provides subtle but elegant illumination when you switch your life at night.
3. Exquisite craftsmanship shapes the edges more smoothly while giving the lines a better look.
4. Applying PC material at cover and chassis that is highly resistant to fire, discoloration, scratchesand fading, this double pole switch can provide you a safety environment.
5.Each new product comes with one pack of fixing screws, and packing can be customized.
6. Features a contemporary style, and cover, insert and buttons come in a wide range of colors and finishes. Matt switch button can be done to polish finish, painting finish even with varnish and other injection colors.
7. LED dimmer switch and Fan dimmer switch are available for you to create your ideal atmosphere.
8. Double pole switch not only gives you the visual enjoyment but also provides10-year warranty and double safety, so you have always got sense of security.
9. Thanks to the compact mechanismsand convenient locking at frames, this wall switch provides time-saving and space-saving solutions.
10. SOK is one of the brands in our company named Guangdong Jinli Electrical Appliance Co., Ltd which was established in 1985. As one of the biggest manufacturer in China, Jinli devotes to making light switches and socket outlets for 35 years. Whereafter Jinli has developed into a group that rapidly expands its business including domestic business, exporting business, real estate business and finance business.
Product Parameter (specification) of the 20AX 250V Double Pole Switch with Neon - White 1 Gang
| Main | |
| Type | Wall Switch |
| Series | W83 series |
| Brand Name | SOK |
| Model Number | W83/20L1 |
| Color | White or customized |
| Material | PC, PP, Copper, Silver |
| Complementary | |
| Rated Voltage | 250V~ |
| Rated Current | 20AX |
| Network Frequency | 50/60Hz |
| Number of Gangs | 1 Gang |
| Function | Double pole switch |
| Actuator | Rocker |
| Device Mounting | Flush wall mounted |
| Fixing type | Concealed screws |
| Fixing Mode | By screw M3.5 |
| Fixing Screws Material | Zinc-plated |
| Connections | Screw terminals(pillar terminal)M3*6.5mm |
| Contacts Material | Brass |
| Embedding Depth | 25 mm |
| Dimension | 86*86mm |
| Environment | |
| Ambient Air Temperature for Operation | -5~40℃ |
| Flame Retardancy | 850℃ |
| IP degree of protection | IP20 |
| Standards | BS EN 60669-1 |
| Application | House, Commercial, Industrial, Hospital, Residential using |
| Contractual Warranty & Tested Lifetime | |
| Tested Lifetime | At least 40,000 times |
| Warranty | 10 years |
| Packing | |
| Packing | 1 pcs/ plastic bag 150*120mm
10pcs/box 185*154*93mm 100pcs/carton 490*320*200mm |
| More Info. | |
| Payment term | T/T, L/C, D/P... |
| MOQ | 3000 pcs |
| Manufacture | Guangdong Jinli |
| Place of Origin | Guangdong, China |
| Certificate | CB,CE,SASO,GCC, Jinli factory Successfully certified with ISO9001 & ISO14001 quality system certificate |
Product Details of the 20AX 250V Double Pole Switch with Neon - White 1 Gang
MOLD WORKSHOP & INJECTION WORKSHOP
BEAUTIFUL OFFICE BUILDING
Jinli factory Successfully certified with ISO9001 & ISO14001 quality system certificate & CNAS TEST LAB
We have developed over 20 product series containing Europe, Italy and British standards which meets the demands of 96% countries in the world. And our products have obtained CE, CB, ROHS, TUV, VDE, SASO, GCC, Inmetro certificates. We are confident to provide you best service.
STANDARD PACKING
