13A 250V Fused Outlet - 1 Gang White

Series: W50 Series

Model No.: W50/FO

Color: White

Size: 86X86 mm

Quality Assurance:10 years

Standard: British

Certificates: CB, CE, SASO, GCC





As a supplemental electric wiring device, this Fused Outlet is the one you’re looking for. Glossy surface, smooth corners, thin profile and pure white color, all these are aesthetic pleasing and elegant.



Product Introduction of the 13A 250V Fused Outlet - 1 Gang White

1. Features an elegant and clean outlook with a concealed-screwdesign. Also, it’s durable and easier to clean.

2. Insert to two holes by slotted screwdriver from the side to disassemble, and lightly lock the cover plate to the surround after fixing the item on wall.

3. With fuse, and ground terminals are connected to Earth wire, which can prevent the risk of electric shock.

4. Selects high polymer PC material on cover and shell frame, which is resistant to discoloration, impact, heating, scratches and fading.

5. Customization is welcome. Product can be changed to other injection color or painting color to match your room’s tone. If you have any ideas of customizing, please feel free to contact us.

6. Fused outlet with neon, communication outlet, dimmer switch available.

7. Ideal for residential building, industrial project, office and factory.

8. Our company covers 300,000 square meters, and there are coloring workshop, injection workshop, mold manufacturing workshop, metal parts punching workshop, assembly workshop, warehouses, CNAS certified laboratory and beautiful office building.



Product Parameter (specification) of the 13A 250V Fused Outlet - 1 Gang White

Main
Type Fused Flex outlet
Series W50 series
Brand Name SOK
Model Number W50/FO
Color White, can be customized
Material High polymer PC
Complementary
Number of Gangs 1 Gang
Device Mounting Flush or surface mounted
Fixing type Concealed screws
Fixing Mode By screw M3.5*25mm
Fixing Screws Material Zinc-plated
Connections Screw terminals(pillar terminal)M3.5*6.5mm
Contacts Material Brass
Rivets Material Brass
Embedding Depth 15 mm
Dimension 86*86mm
Environment
Flame Retardancy 850℃
Application Industrial, Hotel, Club, Restaurant, Hospital, Residential
Contractual Warranty
Warranty 10 years
Packing
Packing

1 pcs/ plastic bag 150*120mm

10pcs/box 185*154*93mm

100pcs/carton 490*320*200mm

More Info.
Payment term T/T, L/C, D/P, D/A...
MOQ 3000 pcs
Manufacture Guangdong Jinli
Place of Origin Guangdong, China
Certificate ROHS, CB, CE, SASO, GCC, ISO9001 & ISO14000



Product Features and Application of the 13A 250V Fused Outlet - 1 Gang White



Product Details of the 13A 250V Fused Outlet - 1 Gang White

Assembling  Instruction:



FAQ of the 13A 250V Fused Outlet - 1 Gang White



Q: Hows your guarantee policy?



A: We provide 10-year guarantee for two way switch, double pole switch, 2 pin socket, Intermediate switch, British outlets, modular switches, German socket outlet, different plug socket. And 2-year warranty for electronic products like USB outlets quick charge 3.1/2.1A, dimmer light switch, Thermostats, motion sensor light switch, etc.







Q: What certification have you obtained?



A:We have obtained SASO, GCC, CE, CB, ROHS, TUV, VDE, Inmetro for products, and our company has ISO14001, ISO9001, OHSAS18000 certification.





Q: Can you help customers mixing cargo in one container?



A: Yes. We can help as we have warehouses with loading platforms to mix different kinds of products in one container to make it full to reduce your cost. We could supply professional loading plan for you.





Q: How about your quality guarantee?



A: 100% inspection for each product, Temperature Rise and Test Life test for switches and sockets, Salty Spray Test for screws.
